Part Number | X Thread in | L in | D in | D1 in | D2 in | D3 in | H in | H1 in | H3 in | H4 in | A1 in | A2 in | No. of Teeth |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
06400-1A32X20 | 5/16-18 | .79 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A32X25 | 5/16-18 | .98 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A32X30 | 5/16-18 | 1.18 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A32X40 | 5/16-18 | 1.57 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A32X50 | 5/16-18 | 1.97 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A32X60 | 5/16-18 | 2.36 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A42X20 | 3/8-16 | .79 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A42X25 | 3/8-16 | .98 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A42X30 | 3/8-16 | 1.18 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
06400-1A42X40 | 3/8-16 | 1.57 | .53 | 1.3 | .98 | .39 | .75 | .08 | .91 | 1.14 | 4.02 | .59 | 26 |
